TECHNICAL SPECIFICATIONS

uPVC Glazing Bead Saw Machine for windows and doors.
– The machine has desined for cutting uPVC glazing bead profiles between
+45° / -45° to fit the glass to the window.
– Vertical pneumatic clamping system.
– Universal adjustable molds for all kind of uPVC profiles is included.
– Left side measuring conveyor is inclued.
– Small blade helps to notch profile for after welding scraps.
– 4 saw blades, 2 on each motor.
– Notch cutting depth can be adjusted according to the desired levels.

STANDARD VOLTAGE380 V
FREQUENCY50 Hz
TOTAL POWER1.5 KW
AIR PRESSURE6 Bar Min.
AIR TRANSPORT1.40 Lt. Min.
MACHINE WIDTH500 mm.
MACHINE LENGTH1100 mm.
MACHINE HEIGHT1100 mm.
MACHINE WEIGHT120 Kg.
